Schneider HMIGTO6310 Touch Screen Glass Protective Film

Schneider HMIGTO6310 Touch Screen Glass Protective Film

Detail Information

Schneider HMIGTO6310 HMI-GTO6310 Touch Screen Panel Glass Protective Film repair replacement

Order each part separately is available

Schneider Magelis HMIGTO6310 Touch Screen Panel

The HMIGTO6310 Touch Screen Panel is use to repair HMI that make use of a resistive touchscreen technology.The touch screen working temperature operating range: -10° C ~ 60° C. And gunze touch screen display Resistance 300Ω < X Axis <900Ω , 200Ω < Y Axis <800Ω (Varies with different size).
The HMIGTO6310 panel has the following features on the front:
1. A touch screen for displaying synoptic views (12.1” color TFT).
2. A multicolor indicator (green, orange and red) showing the panel’s operating mode.


The front face of the HMIGTO, installed in a solid panel, has been tested using conditions equivalent to the standards shown in the specification. Even though the HMIGTO's level of resistance is equivalent to these standards, oils that should have no effect on the HMIGTO can possibly harm the panel. This can occur in areas where either vaporized oils are present, or where low viscosity cutting oils are allowed to adhere to the panel for long periods of time. If the panel's front face protection sheet peels off, these conditions can lead to the ingress of oil into the panel and separate protection measures are suggested.




Specifications:

The table below describes the parameters of the HMIGTO6310 touchscreen protective film.

Part Number : HMIGTO6310
Product Line: Magelis GTO Series
Touchscreen Size: 12.1 in.
Warranty: 1-Year Warranty
Touch Technology: Resistive Film (analog)
Resolution: DC 5V 1mA
Operating Temp.: 1024 X 1024
Storage Temp.: -20℃~+70℃
lineation test: ≥1.000.000 times
Input Type: ≥100.000 times

PDF Download:

  • Magelis HMIGTO6310 User Manual and Product datasheet
  • Magelis GTO Advanced Panels Catalog PDF
  • MagelisHMI GTO for Vijeo DesignerUser Manual

  • Magelis GTO Series Part No.

    Magelis GTO Description Inventory status
    HMIGTO1300 3.5” QVGA TFT LCD screen In Stock
    HMIGTO1310 3.5” QVGA TFT LCD touchscreen In Stock
    HMIGTO2300 5.7” QVGA TFT LCD screen Available Now
    HMIGTO2310 5.7” QVGA TFT LCD touchscreen In Stock
    HMIGTO2315 5.7” QVGA TFT LCD touch panel Available Now
    HMIGTO3510 7.0” WVGA (Wide) TFT LCD screen In Stock
    HMIGTO4310 7.5” VGA TFT LCD screen Available Now
    HMIGTO5310 10.4” VGA TFT LCD screen In Stock
    HMIGTO5315 10.4” VGA TFT LCD touchscreen In Stock
    HMIGTO6310 12.1” SVGA TFT LCD screen Available Now
    HMIGTO6315 12.1” SVGA screen In Stock
    Schneider HMIGTO Description Inventory status

    Common misspellings:

    MHIGTO6310

    HIMGTO6310

    HMIGTO3610

    HMIGTO6130

    HMIGTO6301
