Magelis HMIGTO1300 Touchscreen Panel Protective Film

Magelis HMIGTO1300 Touchscreen Panel Protective Film

Detail Information

Schneider Magelis HMIGTO1300 HMI-GTO1300 Touch Screen Panel Protective Film repair replacement

Order each part separately is available

Schneider Magelis HMIGTO1300 HMI-GTO1300 Touch Screen Panel

The Schneider HMIGTO1300 touch screen panel with protective film, which is manufactured with resistance touch screen technology that can be touch with fingers. The display screen size is 3.5 inch and 65536 display colours, and these are have 6 push-button, marking: F1...F6, number of function keys = 6 (operation defined using Vijeo Designer).It HMIGTO1300 touchscreen working most high temperature and high humidity storage: 70℃,70%RH and 120hr. Basically meet various industrial automation control panel working environments


All Magelis terminals feature an integrated RS 232 C or RS 422/485 asynchronous serial link. Use of the Uni-TE or Modbus protocol makes it easy to set up communication with Schneider Electric PLCs.


This computer uses the Magelis Professional operating system and the configuration of the HMIGTO1300 HMI is done by using the Configuration software Vijeo Designer. When in operation, it is important that its ambient temperature is within the 32 to 125 degrees Fahrenheit or 0 to 50 degrees Celsius range. And its ambient temperature for storage within the -20 to 60 degrees Celsius range. It can basically meet the requirements of working in a normal environment




Specifications:

The table below describes the parameters of the HMIGTO1300 touchscreen protective film.

Part Number : HMIGTO1300
Product Line: Magelis GTO Series
Touchscreen Size: 3.5 in.
Warranty: 1-Year Warranty
Touch Technology: Resistive Film (analog)
Resolution: DC 5V 1mA
Operating Temp.: 1024 X 1024
Storage Temp.: -20℃~+70℃
lineation test: ≥1.000.000 times
Input Type: ≥100.000 times

PDF Download:

  • Magelis HMIGTO1300 User Manual and Product datasheet Characteristics
  • Magelis GTO Advanced Panels Catalog PDF
  • MagelisHMI GTO for Vijeo DesignerUser Manual

  • Magelis GTO Series Part No.

    Magelis GTO Description Inventory status
    HMIGTO1300 3.5” QVGA TFT LCD screen In Stock
    HMIGTO1310 3.5” QVGA TFT LCD touchscreen In Stock
    HMIGTO2300 5.7” QVGA TFT LCD screen Available Now
    HMIGTO2310 5.7” QVGA TFT LCD touchscreen In Stock
    HMIGTO2315 5.7” QVGA TFT LCD touch panel Available Now
    HMIGTO3510 7.0” WVGA (Wide) TFT LCD screen In Stock
    HMIGTO4310 7.5” VGA TFT LCD screen Available Now
    HMIGTO5310 10.4” VGA TFT LCD screen In Stock
    HMIGTO5315 10.4” VGA TFT LCD touchscreen In Stock
    HMIGTO6310 12.1” SVGA TFT LCD screen Available Now
    HMIGTO6315 12.1” SVGA screen In Stock
    Schneider HMIGTO Description Inventory status
