Magelis HMIGTO2300 Touchscreen Panel Protective Film

Magelis HMIGTO2300 Touchscreen Panel Protective Film

Detail Information

Schneider Magelis HMIGTO2300 HMI-GTO2300 Touch Screen Panel Protective Film repair replacement

Order each part separately is available

Schneider Magelis HMIGTO2300 HMI-GTO2300 Touch Screen Panel protective film

The HMIGTO2300 HMI touchscreen is a Schneider Magelis GTO HMI Panels 5.7" HMI that make use of a resistive touch screen panel. It come with a 5.7-inch analog resistive 4-wire touch screen and Dig 16 inputs/10 outputs. It also belongs to the monochrome controller pane.


When connecting the XBTZGI232, the COM port's pin 9 setting should be VCC. You can define COM port settings in Vijeo Designer or in the HMIGTO's offline menu. The RS-232C Isolation Unit works with only RS-422/485 (4 wire) communication.Cable-Gateway for Siemens Profibus / MPI (XBT ZG9292) is not supported by HMIGTO2300.


The Magelis HMIGTO2300touch panel 5.7 inch color touch controller panel - Dig 8 inputs/8 outputs +Ana 4 In/2 Out. The STN dispaly backlight allows dimming and energy efficient and the Pixel resolution with 320 x 240 pixels QVGA. The integrated design of the Magelis GTO HMI touchscreen delivers maximum functionality while keeping installation easy. Especially suitable for small machines and simple process control, its state-of-the-art display provides a crystal-clear readability.



Specifications:

The table below describes the parameters of the HMIGTO2300 touchscreen protective film.

Part Number : HMIGTO2300
Product Line: Magelis GTO Series
Touchscreen Size: 5.7 in.
Warranty: 1-Year Warranty
Touch Technology: Resistive Film (analog)
Resolution: DC 5V 1mA
Operating Temp.: 1024 X 1024
Storage Temp.: -20℃~+70℃
lineation test: ≥1.000.000 times
Input Type: ≥100.000 times

PDF Download:

  • Magelis HMIGTO2300 User Manual and Product datasheet Characteristics
  • Magelis GTO Advanced Panels Catalog PDF
  • MagelisHMI GTO for Vijeo DesignerUser Manual

  • Magelis GTO Series Part No.

    Magelis GTO Description Inventory status
    HMIGTO1300 3.5” QVGA TFT LCD screen In Stock
    HMIGTO1310 3.5” QVGA TFT LCD touchscreen In Stock
    HMIGTO2300 5.7” QVGA TFT LCD screen Available Now
    HMIGTO2310 5.7” QVGA TFT LCD touchscreen In Stock
    HMIGTO2315 5.7” QVGA TFT LCD touch panel Available Now
    HMIGTO3510 7.0” WVGA (Wide) TFT LCD screen In Stock
    HMIGTO4310 7.5” VGA TFT LCD screen Available Now
    HMIGTO5310 10.4” VGA TFT LCD screen In Stock
    HMIGTO5315 10.4” VGA TFT LCD touchscreen In Stock
    HMIGTO6310 12.1” SVGA TFT LCD screen Available Now
    HMIGTO6315 12.1” SVGA screen In Stock
    Schneider HMIGTO Description Inventory status
