B&R 5D5600.01 Provit 5600 Membrane Keyboard Keypad

B&R Provit 5600 5D5600.01 Operator Panel Keypad Repair Replacement

The B&R Provit 5600 5D5600.01 lithium battery (3 V, 950 mAh) keeps the CMOS memory and real-time clock running when the supply voltage for the B&R Provit 5600 5D5600-01 IPC has been switched off. The buffer duration of the battery is at least 4 years (at 50°C, 8.5 mA current requirements of the supplied components and a self-discharge of 40%). The B&R Provit 5600 5D5600.01 reset button is accessible through a small hole near the external floppy disk drive interface. In order to avoid accidental activation, a B&R Provit 5600 5D5600.01 reset can only be triggered with a pointed object.

In the IPC5600/IPC5600C, 5D5600.01 BIOS enables the LS120 drives (which are actually IDE devices such as CD-ROM drives) to operate like a disk drive (drive letter A or B). However, it is only possible to use standard diskettes (360 KB, 720 KB, 1.44 MB) with the LS120 drive. The 5D5600.01 option to work with special 120 MB diskettes is not a built-in feature of BIOS and must be supported by the operating system. If an LS120 drive is operated without a second disk drive (in BIOS "Floppy A = None" and "Floppy B = None", then it can be accessed as the A 5D5600.01 drive and therefore can also be booted. If another disk drive is being used (parallel to the LS120 drive) in addition to the external disk drive interface, then the disk drive is operated as drive A and the LS120 drive is operated as drive B. In this case, the 5D5600.01 expression "LS/Zip" must be first in the "Boot Sequence" parameter so that the LS120 drive can be used for booting.

Specifications:

The table below describes the parameters of the 5D5600.01 Provit 5600 Membrane Keypad Switch.

Related Provit Series Part No. :

Common misspellings:

5D560.01

5D5600.0

5D6500.01

5D5600.0l

5D56600.01
