IDEC HG2A-SB22BF Touch Screen Panel Replacement
IDEC HG2A-SB22BF Touch Screen Panel Replacement
| Categories | HG2A, HG2S, FT1A 3.8-inch PLC+HMI |
|---|---|
| Brand | VICPAS |
| Model | HG2A-SB22BF |
| Warranty | 365 Days |
| Shipping | 2-4 workdays |
| Brand | IDEC |
| Supply Parts | Touch Screen Display |
| Size | 5.7 inches |
| FOB port | Guangzhou, Shenzhen, Hongkong |
| Terms of Payment | Western Union, MoneyGram, T/T, Paypal, PayPal, T/T ,Credit Card, Western Union |
| Update Time | Dec 25,2024 |
IDEC HG2A Series HG2A-SB22BF Touch Screen Film Replacement
Instruction for protective sheet
The Protective Sheet of HG2A-SB22BF Touch Membrane is replaceable, transparent sheet to protect a display of HG series. With the protective sheet covered on the display, you can operate touch switches.
1. Wipe any dirt off the HG2A-SB22BF Touch Screen Glass using a soft cloth slightly dampened with neutral detergent or alcoholic solvent.
2. Remove the back sheet of the protective sheet.
3. The tab of the protective sheet should be positioned at lower left. Align the right side of the protective sheet with that of the HG2A-SB22BF Touch Screen Film, then apply the protective sheet onto the display. Care should be taken to avoid the ingress of air.
4. On the top of the protective sheet, a thin cover sheet is applied to prevent the protective sheet from being damaged during transportation. Remove it before using the display of HG series.
When a protective sheet of HG2A-SB22BF HMI Touch Glass gets dirty or damaged, replace the protective sheet with a new one. When replacing the sheet, remove the used adhesives completely. The Protective Sheet has no protection effect against chemicals. This HG2A-SB22BF Touch Digitizer has used a special material to filter out UV rays, however no warranty is given as to be installed in direct sunlight of outside.
Specifications:
The table below describes the parameters of the IDEC HG2A-SB22BF Touch Screen HMI.
| Brand: | IDEC |
| Mounting: | Panel Mounting |
| Degree of protection: | IP65 |
| Touchscreen: | Analog Resistive |
| Warranty: | 1-Year Warranty |
| Display Type: | TFT Color |
| Screen Type: | Analog Resistive Film |
| Model Number: | HG2A-SB22BF |
| Operating Temperature: | 0 ~ 50°C |
| Storage Temperature: | -25 ~ 60°C |
Related IDEC HMI No. :
| IDEC HMI | Description | Inventory status |
| HG2A-SB22CF | IDEC HG2A Series Touch Digitizer Glass Repair | Available Now |
| HG2A-SB22CT | IDEC HG2A Series Touch Membrane Replacement | In Stock |
| HG2A-SB22JF | IDEC HG2A Series Touch Screen Glass Repair | Available Now |
| HG2A-SB22VF | IDEC HG2A Series Touch Screen Display Replacement | In Stock |
| HG2A-SS22BF | IDEC HG2A Series HMI Panel Screen Repair | Available Now |
| HG2A-SS22CF | IDEC HG2A Series Touchscreen Monitor Replacement | In Stock |
| HG2A-SS22CT | IDEC HG2A Series Touch Screen Film Repair | Available Now |
| HG2A-SS22JF | IDEC HG2A Series Touch Screen Tablet Replacement | In Stock |
| HG2A-SS22VF | IDEC HG2A Series HMI Touch Glass Repair | Available Now |
| IDEC HMI | Description | Inventory status |
IDEC HG2A Series Manuals PDF Download:
FAQ:
Question: What should I pay attention to during operation?
Answer: During operation, the screen becomes blank when the backlight is burnt out; however, the touch panel of HG2A-SB22BF Terminal remains enabled. Incorrect touch panel operation will occur when operating the touch panel when the backlight appears to be turned off but is actually burnt out. Note that this erroneous operation may result in damage.
Question: What are the screen types of HG2A-SB22BF machine?
Answer: The screen types of HG2A-SB22BF HMI are base screen, popup screen and system screen.
Question: How to maintain HG2A-SB22BF HMI Touch Glass?
Answer: To wipe off smears on the lens and the surfaces of HG2A-SB22BF Touch Screen, use a soft cloth dampened with the following solvents. Use neutral detergent(squeeze the cloth tightly) or alcoholic solvents. Do not use solvents such as thinner, ammonia, strong acid and strong alkaline.
Common misspellings:
G2A-SB22BF
HG2A-B22BF
HG22A-SB22BF
HG2A-SB22BFF
HG2A-S2B2BF
