B&R 5D5213.02 Provit 5200 Touch Screen Organizer

B&R 5D5213.02 Provit 5200 Touch Screen Organizer

B&R 5D5213.02 Provit 5200 Touch Screen Organizer
B&R 5D5213.02 Provit 5200 Touch Screen OrganizerB&R 5D5213.02 Provit 5200 Touch Screen Organizer
CategoriesProvit 2000/5000
BrandVICPAS
Model5D5213.02
Touch screen panel typeResistance touch screen
Size18.1 inch
BrandB&R
Warranty1 Year VICPAS Warranty
ModelB&R Provit 5200 5D5213.02
ShippingDHL/FedEx/UPS/TNT/EMS/Aramex /DPEX
FOB portGuangzhou, Shenzhen, Hongkong
Terms of PaymentWestern Union, T/T, PayPal, Credit Card
Update TimeNov 22,2024
Detail Information

B&R Provit 5200 5D5213.02 Touch Screen Glass Repair Replacement

Provit 5200 5D5213.02 Touch Screen Panel

The B&R Provit 5200 5D5213.02 lithium battery (3 V, 950 mAh) keeps the CMOS memory and real-time clock running when the supply voltage for the B&R Provit 5200 5D5213.02 IPC has been switched off. The buffer duration of the battery is at least 4 years (at 50°C, 8.5 mA current requirements of the supplied components and a self-discharge of 40%). The B&R Provit 5200 5D5213-02 reset button is accessible through a small hole near the external floppy disk drive interface. In order to avoid accidental activation, a B&R Provit 5200 5D5213.02 reset can only be triggered with a pointed object.


The B&R Provit 5200 5D5213-02 MTC is responsible for the following tasks and components:
• AT PS/2 keyboard
• Panelware keypad modules
• Acquisition of operating data (controller and display unit)
• Temperature monitoring with fan regulation
• Qualitative evaluation of the condition of the battery (good/bad)


  Contact Best Price


Specifications:

The table below describes the parameters of the 5D5213.02 Provit 5200 Touchscreen Panel.

Part Number : 5D5213.02
Product Line:Provit 5200
Screen diagonal18.1 in
Warranty: 365 Days Warranty
Input Power24 VDC
Display Type:TFT color
Mounting position: Vertical
Input Type: Touchscreen
Serial interface Type:RS232
Storage -20 to 50°C


Related Provit Series Part No. :

B&R Provit Description Inventory status
5D5200.04 B&R Provit 5200 Touch Digitizer Glass In Stock
5D5202.01 Provit 5200 B and R Touch Screen Panel Available Now
5D5202.03 B&R Provit 5200 HMI Touch Glass Repair In Stock
5D5212.01 Provit 5200 B and R Touch Digitizer Glass Available Now
5D5202.05 Provit 5200 B and R Touch Screen Monitor In Stock
5D5212.02 B&R Provit 5200 Touch Screen Protective Film In Stock
5D5212.04 B&R Provit 5200 Touch Screen Glass Repair In Stock
5D5212.26 Provit 5200 B and R Touch Digitizer Glass Available Now
5D5213.01 B and R Provit 5200 HMI Panel Glass Repair Available Now
5D5213.02 B&R Provit 5200 Touch Screen Monitor Available Now
5D5501.20 Provit 5500 B&R Keyboard Membrane Touch Screen In Stock
B and R Provit Description Inventory status

FAQ:

Question:How to change the B&R Provit 5200 5D5213.02 Battery?

Answer:
1. Disconnect the power supply
2. Touch the housing or ground connection (not the power supply!) in order to discharge any electrostatic charge from your body.
3. Remove the battery compartment cover.
4. Remove the battery by pulling the removal strip (do not use - pliers or uninsulated tools! --> risk of short circuiting).
5. The battery should not be held by its ends. Insulated tweezers may also be used for removing the battery.
How to change the B&R Provit 5200 5D5213.02 Battery?
6. Insert the new battery with correct polarity. The removal strip should be protruding from the battery holder and the "+" side of the battery should be facing downward. To be able to remove the battery again, the removal strip must protrude from the upper side of the battery.
7. Now wrap the end of the removal strip over the top of the battery and insert it underneath the battery so that it does not protrude from the battery holder.
8. Replace cover.
9. Reconnect the power supply.
10. Set the date and time
How to change the B&R Provit 5200 5D5213.02 Battery?


Question: What is the B&R Provit 5200 5D5213.02 touch screen panel price?

Answer: Submit a fast quote, send VICPAS an email for best price.

Common misspellings:

5D523.02

D5213.02

5D5123.02

5D5213.O2
