Membrane keyboard for 6AV6641-0CA01-0AX1 OP77B membrane keypad switch
Membrane keyboard for 6AV6641-0CA01-0AX1 OP77B membrane keypad switch
| Categories | Simatic OP7 OP77A/B OP 73 |
|---|---|
| Brand | VICPAS |
| Model | 6AV6 641-0CA01-0AX1 |
| Warranty | 180 days warranty |
| Brand | Siemens Simatic OP77b |
| Shipping | DHL/FedEx/UPS/TNT/EMS |
| Models | 6AV6641-0CA01-0AX1 |
| Parts | Keypad and Case Shell |
| Product Line | Siemens Operator Panel |
| FOB port | Guangzhou, Shenzhen, Hongkong |
| Terms of Payment | Western Union, MoneyGram, T/T, Paypal, PayPal, T/T ,Credit Card, Western Union |
| Update Time | Nov 22,2024 |
Siemens OP77B 6AV6641-0CA01-0AX1 Operator Panel Keyboard, Screws, Power Supply Connector, Mounting Clips, Gasket and 6AV6 641-0CA01-0AX1 Plastic Shell Case Replacement Repair
Order each part separately is available
The 6AV6 641-0CA01-0AX0 operator panel is belong the Siemens OP77b operator panel series, it is small and smart. VICPAS provides the new keypad switch, Mounting Clips, Power Supply Connector, Gasket, Screws and case to replace the Simatic OP77b keypad and cover, which is supported 180 days VICPAS warranty.
The Siemens OP77B 6AV6641-0CA01-0AX0 was designed as a low-cost operator control with rugged keys for small-scale HMI tasks. 4.5" monochrome STN liquid crystal display (LCD) with membrane keypad & MPI/Profibus-DP interface (12MB). The front of op7 is resistant to various oils, greases and standard detergents. Plug-type terminals for connection of a 24 V DC power supply. RS 485 interface for process links (MPI, PROFIBUS DP up to 1.5 Mbit/s) and for downloading the configuration.
Specifications:
The table below describes the parameters of the Siemens OP77B 6AV6641-0CA01-0AX1 Operator Panel keypad and case.
| Part Number : | 6AV6641-0CA01-0AX1 |
| Product Line: | Siemens Simatic OP77B |
| Product's Size: | 4.5 inches |
| Warranty: | 180 Days Warranty |
| Material: | Polyester or Polycarbonate |
| Rated Voltage: | DC 5V 1mA |
| Operating Temp.: | -10℃～+80℃ |
| Storage Temp.: | -20℃～+70℃ |
| Conductive Trace: | Silver or Copper |
| Life Cycle: | 5 Million Cycles(up to) |
Related Siemens Simatic OP77 Part No. :
| Siemens OP77a OP77b HMI | Description | Inventory status |
| 6AV6641-0CA01-0AX0 | SIMATIC OPERATOR PANEL OP77B Keypad and Case Shell | In Stock |
| 6AV6641-0CA01-0AX1 | OPERATOR PANEL OP77B (2C) Keyboard and Plastic Case Shell | In Stock |
| 6AV6641-0BA11-0AX1 | SIMATIC OPERATOR PANEL OP77A Keypad and Case Shell Cover | In Stock |
| 6AV6641-0BA11-0AX0 | Siemens OP77a Membrane Keypad and Front Case Shell | Available Now |
| 6AG1641-0CA01-4AX1 | SIPLUS HMI OP77B Membrane Keyboard and Case Shell | In Stock |
| 6AG1641-0CA01-4AX0 | SIPLUS OP77B Siemens Keypad and Case Shell Cover | In Stock |
| 6AV6651-1CA01-0AA0 | Starter Package OP77A OP 77A Panel Keypad and Case | In Stock |
| 6AV6651-1BA01-0AA0 | Starter Package OP77A OP 77B Panel Keyboard and Plastic Case Shell | Available Now |
| Simatic OP77 Operator Panel | Description | Inventory status |
Complete view of all series Siemens HMI Parts
Siemens OP77B 6AV6641-0CA01-0AX1 Manual PDF Download:
FAQ:
Question: How to Backup and restore a program on Siemens OP77B 6AV6641-0CA01-0AX1 Operator panel?
Answer: This feature allow to upload only the compiled file. Let's call an image file downloaded to the Panel. Image file executed only on the panel and you can restoreit using Prosave software to the same panel again or another panel with the same MLFB. You will not be able to modify any thing in this file. And also you do not need to buy a licenced software (WinCC flexible), you can backup and restore using Prosave software and it is a free ware and can be downloaded from siemens Website.
Then follow the instructions of Siemens technical support: Siemens Simatic OP77A OP77B Backup
Question: What software does Siemens OP77B 6AV6641-0CA01-0AX1 operator panels use?
Answer: It is SIMATIC WinCC Flexible software, that is an integrated family of tools for configuring theSiemens OP77B 6AV6641-0CA01-0AX1 operator panels operator units. The uniformity of configuration software reduces training, maintenance and updating requirements . More details download the PDF Siemens Software WinCC-flexible 2008
Question: What is the difference between OP77A vs OP77B?
Answer: The functions of these two products are the same, but his internal configuration is partially different. The Siemens OP77A version has 256 KB memory and the Simatic OP77b version 1MB + optional MMC. The A-version definitely has an RS485 interface. Aad The B version also has USB, RS232 and RS422
Question: How do you back transfer the projects of Siemens OP77B 6AV6641-0CA01-0AX1 HMI Panel?
Answer:Back transfer of the project: This feature allow to have a copy of the WinCC project from Simatic Panel. In this case, you can open this project from WinCC flexible and modify if you want.
Then follow the instructions of Siemens technical support: How do you back transfer the projects of an operator panel and what should you watch out for?
Question: What is the Siemens OP77B 6AV6641-0CA01-0AX1 price of membrane keypad and case?
Answer: Submit a fast quote, send VICPAS an email for best price.
