PPC-306-PN6BU PPC-306-PN6C PPC-306-PN6D PPC-306-RN6AU Protective Film Touchpad

Order each part separately is available

Mounting Instruction

When mounting the HMI Advantech PPC-306 EHL Series PPC-306-PN6BU PPC-306-PN6C PPC-306-PN6D PPC-306-RN6AU Touch Digitizer Glass Front Overlay, more than one person should perform the installation. Be careful and prevent accidental damage to the Advantech HMI PPC-306-PN6BU PPC-306-PN6C PPC-306-PN6D PPC-306-RN6AU Protective Film Touch Screen Panel or personal injury.

Wall Mounting

1. Select the location on the wall for the wall mount plate.
2. Mark the locations of the two plate screw holes on the wall.
3. Drill two pilot holes at the marked locations on the wall.
4. Align the wall mount plate screw holes with the pilot holes.
5. Secure the mount plate to the wall by inserting screws into the two pilot holes and tightening them. Be careful not to drop the Advantech screen PPC-306-PN6BU PPC-306-PN6C PPC-306-PN6D PPC-306-RN6AU Front Overlay Touch Membrane to the ground.
6. Insert four M4 screws into the holes on the panel PC and tighten them to secure the bracket to the rear panel. Check the stability of Advantech PPC-306-PN6BU PPC-306-PN6C PPC-306-PN6D PPC-306-RN6AU touch screen HMI Touch Glass Protective Film again.
7. To mount the panel PC on the wall, align the wall mount bracket attached to the panel PC with the wall mount plate on the wall and slide the panel PC downward to hang the bracket on the mount plate.
8. Secure the panel PC in place by tightening the screws into the wall mount bracket.
