Koyo EA3 EA3-T6CL Touch Screen Front Overlay Replacement

Koyo EA3 EA3-T6CL Touch Screen Front Overlay Replacement

Koyo EA3 EA3-T6CL Touch Screen Front Overlay Replacement
Koyo EA3 EA3-T6CL Touch Screen Front Overlay ReplacementKoyo EA3 EA3-T6CL Touch Screen Front Overlay ReplacementKoyo EA3 EA3-T6CL Touch Screen Front Overlay Replacement
CategoriesC-more Micro Panels
BrandVICPAS
ModelEA3-T6CL
BrandKOYO
Size6 inch
Warranty365 Days
Product LineKoyo C-more Micro Panels EA3 Series
SupplyEA3-T6CL Touch Digitizer Glass Front Overlay
Shipping2-4 workdays
Terms of PaymentWestern Union, T/T, PayPal, Credit Card
Update TimeDec 25,2024
Detail Information

Koyo C-more EA3 EA3-T6CL HMI Panel Glass Protective Film Repair Replacement


Koyo Micro Panels EA3-T6CL Touch Screen Front Overlay Repair Replacement

Koyo EA3-T6CL Protective Film Touch Screen Terminal Features
• Touch screen display
• Free downloadable programming software
• 320 x 240 pixel display with up to 40 lines by 80 characters of text and graphics in landscape mode
• Up to 40 characters of dynamic text with embedded variables and phrases mixed with graphics
• Five programmable function keys can change with every screen. Can increment / decrement values, trigger recipes, view index of screens.
• 32K colors
• Optional replaceable clear screen overlay
• 6MB memory
• Supports Ethernet expansion module (EA-ECOM)
• Built-in USB type B programming port
• Built-in 15-pin serial communications port
• Built-in RJ12 serial communications port
• Built-in Alarm Control setup that activates beep, backlight flash, customized alarm banner, and red LED blinking
• 0 to 50 °C (32 to 122 °F) operating temperature range (IEC 60068-2-14)
• NEMA 4/4X, IP65 compliant when mounted correctly, indoor use only
• UL, cUL & CE agency approvals


C-more Micro 6-inch TFT EA3-T6CL EA3 Touch Panel
The EA3-T6CL Touch Digitizer Glass Protective Film C-more 6-inch Micro touch panel has a 5.7-inch TFT LCD 320 x 240 pixel display and a palette of 32K colors for customizing objects, screen backgrounds and displaying bitmap graphics. It features five user-defined function keys, each key with a user-defined red LED indicator. The EA3-T6CL Front Overlay HMI Panel Glass C-more 6-inch Micro TFT panels are powered from a Class 2, 12-24 VDC power supply. The panel is NEMA 4/4X indoor when installed correctly.




Specifications:

The table below describes the parameters of the Koyo EA3 EA3-T6CL Protective Film Touch Screen Monitor HMI Parts.

Ambient Temperature: 0°C (32°F) to 50°C (122°F)
Brand: KOYO
Display Brightness: 270 nits (typ)
Product Line: Koyo C-more Micro Panel
Touch Size: 6"
Display Colors: 32768 Colors
Display Type: TFT Color
Power supply: 24 V DC
Resolution: 320 x 240 pixels
Warranty: 12-Month Warranty


Related Koyo Micro Panels HMI Part No. :

KOYO Micro Panels Description Inventory status
EA1-S3ML KOYO Micro Panels EA1 Membrane Keyboard Touch Membrane In Stock
EA1-S3ML-N Koyo C-more Panels EA1 Series Membrane Keyboard Keypad Repair In Stock
EA1-S3MLW Koyo C-more Panels EA1 Series Touch Digitizer Glass Membrane Keypad Repair Available Now
EA1-S3MLW-N KOYO C-more Micro Panels EA1 Operator Panel Keypad Replacement Available Now
EA1-S6ML Koyo C-more Panels EA1 Series Touch Screen Monitor Operator Keyboard In Stock
EA1-S6MLW Koyo C-more Panels EA1 Series Keyboard Membrane MMI Touch Screen Repair In Stock
EA1-T4CL Koyo C-more Panels EA1 Series HMI Touch Screen Protective Film Available Now
EA1-T6CL Koyo C-more Panels EA1 Series Protective Film Touchscreen Repair In Stock
EA3-S3ML Koyo C-more Panels EA3 Series HMI Keypad Membrane Touch Screen Glass Available Now
EA3-S3ML-R Koyo C-more Panels EA3 Series Switch Membrane Touch Screen Panel Repair In Stock
EA3-S3ML-RN KOYO Panels EA3 Series Membrane Keypad Switch Replacement In Stock
EA3-T4CL Koyo Micro Panels EA3 Series Touch Panel Protective Film Repair Available Now
EA3-T6CL KOYO Micro Panels EA3 Front Overlay Touch Membrane In Stock
EA3-T8CL Koyo C-more Panels EA3 Series Touch Glass Front Overlay Repair In Stock
EA3-T10CL Koyo C-more Panels EA3 Series Touch Digitizer Glass Overlay Repair Available Now
Koyo C-more Panel Description Inventory status


KOYO C-more Micro Panels HMI Manuals PDF Download:

  • C-more Micro EA3-S3ML PDF
  • C-more Micro EA3-S3ML-R PDF
  • C-more Micro EA3-S3ML-RN PDF
  • C-more Micro EA3-T4CL PDF
  • C-more Micro EA3-T6CL PDF
  • C-more Micro EA3-T8CL PDF
  • C-more Micro EA3-T10CL PDF
  • C-more Micro Panel EA3 Series contents
  • EA3 Series Panels Hardware User Manual
  • EA-ECOM Ethernet Communications Module

  • FAQ:

    Question: Test Menu – Test Touch Panel

    Solution: Using this test, normal or unusual operation of the analog touch panel can be determined.
    Testing:
    If an area of the touch screen is suspected to be inoperable, touch that area of the screen while in the Test Touch Panel screen mode. The screen pixels should turn black in that area. If the screen pixels do not turn black when touched, then the touch screen is defective or needs to be calibrated.
    Test Menu – Test Touch Panel


    Question: C-more Micro-Graphic Panel Runtime Errors

    Solution: The C-more Micro-Graphic panel includes built-in diagnostics that check for proper operation of the panel when it is running a project that has been transferred to its memory. Faults detected while the panel is running will produce a “Runtime” error. These errors are displayed in a popup window in the center of the panel's display
    Troubleshooting a Panel Runtime Error:
    Follow these steps to troubleshoot a panel runtime error.
    1. Check the panel cable connections.
    2. Cycle power at the panel.
    3. Resend the project.
    4. If the error still occurs, reset the panel back to factory default.

    Common misspellings:

    EA3-TCL
    A3-T6CL
    EA3-6TCL
    EA3-TbCL
    EA33-T6CL
