Panasonic AIG32TQ12D Protective Film Panel Glass

Panasonic AIG32TQ12D Protective Film Panel Glass

Panasonic AIG32TQ12D Protective Film Panel Glass
Panasonic AIG32TQ12D Protective Film Panel GlassPanasonic AIG32TQ12D Protective Film Panel GlassPanasonic AIG32TQ12D Protective Film Panel GlassPanasonic AIG32TQ12D Protective Film Panel GlassPanasonic AIG32TQ12D Protective Film Panel Glass
CategoriesPanasonic GT Series
BrandVICPAS
ModelAIG32TQ12D
BrandPanasonic
Size5.7 inch
Warranty365 Days
Product LinePanasonic GT Series
SupplyGT32 GT32T1 Touch Screen and Overlay
Part NumberAIG32TQ12D
Shipping2-4 workdays
Terms of PaymentWestern Union, T/T, PayPal, Credit Card
Update TimeNov 21,2024
Detail Information

Panasonic GT32 GT32T1 AIG32TQ12D Front Overlay Touch Panel Replacement

Order each part separately is available

Panasonic GT32GT32T1 AIG32TQ12D Front Overlay Touch Screen Repair Replacement

Precautions when connecting Panasonic GT AIG32TQ12D
-If noise is a problem, use a shielded cable and employ countermeasures such as installing a ferrite core if necessary. Also, take measures so that the shielding doesn't peel off and noise such as static electricity does not interfere.
-The number of AIG32TQ12D Touch Screen Panel Glass Front Overlay units, transmission distance and baud rate may differ depending on the device connected. Verify with the AIG32TQ12D Touch Panel Protective Film device being used.
-The maximum cable length for RS232C type is 15 m, also RS422 (5 V) type is 30 m.
-The maximum transmission distance is 500 m for the 24 V RS422 type.
-When connecting to the RS485, it may not be connected depending on the timing for switching between the transmission and reception at the external device. Please check it using the actual equipment.
The Panasonic GT32 GT32T1 AIG32TQ12D Protective Film Touch Digitizer Glass terminal unit setting varies according to the external device to be connected. Confirm it before setting a AIG32TQ12D HMI Panel Glass Front Overlay terminal unit.




Specifications:

The table below describes the parameters of the Panasonic GT32 GT32T1 AIG32TQ12D Touch Screen Monitor Front Overlay HMI Parts.

Backlight: CFL
Brand: Panasonic
Warranty: 365 Days
Product Line: Panasonic GT32T1
Resolution: 320 (W) × 240 (H) dots
Ambient temperature: 0 to +50 °C +32 to +122 °F
Display Type: TFT monochrome LCD
Part Number: AIG32TQ12D
Power supply: 24 V DC
Touch Size: 5.7"


Related Panasonic GT Series HMI Part No. :

Panasonic GT32 Description Inventory status
AIG32MQ02D Panasonic GT32M Touch Screen Protective Film Replacement In Stock
AIG32MQ03D Panasonic GT32 GT32M Touch Panel Protective Film Repair Available Now
AIG32MQ04D Panasonic GT32 GT32M Touchscreen Protective Film Repair In Stock
AIG32MQ05D Panasonic GT32 GT32M HMI Touch Screen Glass Protective Film Available Now
AIG32TQ02D Panasonic GT32 GT32T0 Touch Screen Panel Front Overlay Repair In Stock
AIG32TQ03D Panasonic GT32 GT32T0 Front Overlay Touch Membrane In Stock
AIG32TQ04D Panasonic GT32 GT32T0 Touch Glass Front Overlay Repair In Stock
AIG32TQ05D Panasonic GT32 GT32T0 Touch Digitizer Glass Overlay Repair Available Now
AIG32TQ12D Panasonic GT32 GT32T1 HMI Panel Glass Protective Film Available Now
AIG32TQ13D Panasonic GT32 GT32T1 Touch Screen Monitor Front Overlay In Stock
AIG32TQ14D Panasonic GT32 GT32T1 MMI Touch Screen Front Overlay Replacement In Stock
AIG32TQ15D Panasonic GT32 GT32T1 HMI Touch Screen Protective Film In Stock
Panasonic GT32 Description Inventory status


Panasonic GT Series HMI Manuals PDF Download:

  • GT series Connection with other companies' PLCs Manual
  • GT series General-purpose serial communication Manual
  • GT Series MODBUS(RTU mode) Slave Manual
  • GT series User's Manual
  • Panasonic GT01 GT01R GT05 GT11 GT21C GT32 Series PDF

  • FAQ:

    Question: What to DO If Panasonic AIG32TQ12D Touch Screen Panel is dim?

    Answer:
    1) The power voltage may be low.
    Check the capacity of the power supply unit if it is enough for the GT's power consumption.
    2) The contrast is set too low.
    Bring up the system menu and adjust the contrast.
    3) The AIG32TQ12D backlight is off due to the [Backlight Auto-off] setting in the [Setup] of the GT configuration settings in GTWIN.
    Touching any area of the AIG32TQ12D screen lights that area. If a switch part is set on the touched area, the area will not light even if touched. To change the setting, change the content of the backlight auto-off settings.


    Question: What to DO If Panasonic GT32 GT32T1 AIG32TQ12D Touch Screen is blank?

    Answer:
    1) Power is not on.
    Supply the power supply to the Panasonic AIG32TQ12D Touch Digitizer Glass Protective Film unit as per specifications.
    2) (When only lamp and message parts are configured to the base screen) Value of substitute reference device value does not exist in substitute data.
    Check the address of the substitute reference device and the device values on the PLC side.

    Common misspellings:

    AIG2TQ12D
    AIG32T12D
    AG132TQ12D
    AIG327Q12D
    AIG32TQ112D
