F940WGOT-TWD Front Overlay Touch Membrane Repair

F940WGOT-TWD Front Overlay Touch Membrane Repair

F940WGOT-TWD Front Overlay Touch Membrane Repair
F940WGOT-TWD Front Overlay Touch Membrane RepairF940WGOT-TWD Front Overlay Touch Membrane RepairF940WGOT-TWD Front Overlay Touch Membrane RepairF940WGOT-TWD Front Overlay Touch Membrane RepairF940WGOT-TWD Front Overlay Touch Membrane Repair
CategoriesMitsubishi GOT-F900 Series
BrandVICPAS
ModelF940WGOT-TWD
BrandMitsubishi
Warranty365 Days
Product LineMitsubishi GOT-F900 F940WGOT series
SupplyF940WGOT-TWD Touch Front Overlay Repair Kit
Size6.5 inch
ModelF940WGOT-TWD
FOB portGuangzhou, Shenzhen, Hongkong
Terms of PaymentWestern Union, MoneyGram, T/T, Paypal, PayPal, Credit Card
Download
Update TimeNov 9,2024
Detail Information

Mitsubishi GOT-F900 F940WGOT series HMI F940WGOT-TWD Touch Screen Glass Protective Film Repair Kit.

Order each part separately is available

Mitsubishi F940WGOT series HMI F940WGOT-TWD Touch panel Front overlay Repair Kit

The GOT-F900 Touch screen panel glass and protective film hmi is an open type device (device installed to another device) and must be installed in a conductive control panel or cabinet. It not only assure the safety but also has a large effect to shut down the noise generated from GOT, on the control panel.


The bit device ON/OFF function is provided on the user screen of the GOT-F900 and the forced ON/OFF function is provided on the device monitor screen in the HPP mode. These functions are also available when the SYSMAC C Series PLC is connected as the host unit.


The new GOT-F900 F940WGOT-TWD Touch Screen Tablet Protective Film is suitable for applications in any industry. The new white model GOT provides an additional color option, and the flush frame without the USB port can be cleaned very easily. The GOT can be installed vertically for extra flexibility when installed in confined spaces. VICPAS supply F940WGOT-TWD Mitsubishi F940WGOT Protective Film Touchscreen glass with 365 Days warranty and support Urgent Worldwide Shipping.




  Contact Best Price


Specifications:

The table below describes the parameters of the F940WGOT-TWD Mitsubishi F940WGOT Touch Digitizer Front Overlay.

Part Number: F940WGOT-TWD
Display device:TFT color LCD
Screen diagonal: 6.5 in
Warranty: 365 Days
Product Line:Mitsubishi F940WGOT Series
Input Power:24VDC (+10%, -15%)
Operating Temperature: 0 to 55°C
Resolution:480 x 234 dot
Storage Temperature:-20°C to 60°C
Cooling Method: Self-cooling


Related Mitsubishi F940WGOT Series Part No. :

Mitsubishi GOT-F900 Description Inventory status
F940WGOT-TWD Mitsubishi GOT-F900 Touch Screen Monitor Overlay Repair In Stock
F940WGOT-TWD-C Touch Screen Protective Film Mitsubishi GOT900 F940WGOT Available Now
F940WGOT-TWD-E Mitsubishi F940WGOT Touch Screen Glass Front Overlay In Stock
Mitsubishi F940WGOT HMI Description Inventory status


Mitsubishi GOT-F900 Series HMI Manuals PDF Download:

  • F930GOT Series Installation Manual
  • Mitsubishi Mitsubishi GOT-F900 Brochure
  • Mitsubishi GOT-F900 Operation Manual
  • Graphic Operation Terminal 800 900 series User's Manual

  • FAQ:

    Question: What is the F940WGOT-TWD GOT-F900 F940WGOT touchscreen HMI price?

    Answer: Submit a fast quote, send VICPAS an email for best price.


    Question: What is the Battery Replacement Procedure of Mitsubishi GOT-F900 F940WGOT-TWD?

    Answer:When the battery voltage drop detection device turns ON, immediately replace the battery using the following replacement procedure.

    1) F920GOT-K
    The backlight is not required to be replaced because it is not built in from the beginning (battery-less type).
    2) F930GOT, F933GOT and F930GOT-K
    a) Turn off the power.
    b) Remove the rear cover.
    c) Remove the existing battery from the holder, and disconnect its connector.
    d) Insert the connector of a new battery within 30 seconds.
    e) Insert the new battery into the holder, and attach the cover.What is the Battery Replacement Procedure of Mitsubishi GOT-F900 F940WGOT-TWD?
    3) F940GOT, F943GOT and F940WGOT
    a) Turn off the power.
    b) Open the small slot in the rear cover.
    c) Remove the existing battery from the holder, and disconnect its connector.
    d) Insert the connector of a new battery within 30 seconds.
    e) Insert the new battery into the holder, and close the small slot.What is the Battery Replacement Procedure of Mitsubishi GOT-F900 F940WGOT-TWD?
    4) Handy GOT
    a) Turn off the power.
    b) Remove four mounting screws from the rear cover, then remove the rear cover.
    c) Remove the existing battery from the holder, and disconnect its connector.
    d) Insert the connector of a new battery within 30 seconds.
    e) Insert the new battery into the holder, and attach the cover.What is the Battery Replacement Procedure of Mitsubishi GOT-F900 F940WGOT-TWD?
