4B1270.00-K18 B&R Keyboard Membrane Repair
B&R PANELWARE 4B1270.00-K18 Membrane Keypad Keyboard Repair
The P127 COMPACT HMI 4B1270.00-K18 CAN is a powerful operator panel with a compact design. This 4B1270.00-K18 CAN panel has a 4 x 20 LC display. The display contrast can be set using keys. This 4B1270.00-K18 panel is also equipped with a membrane keypad with 20 keys, 14 of which are illuminated with LEDs. The 14 keys below can be labeled using legend strips. The CAN interface is electrically isolated and uses a 9-pin D-type connector. The baud rate and node number can be set using the number switches on the backside of the unit. All of the functions listed above are integrated into a compact housing (153 x 120 x 43.7 mm).
The P127 4B1270.00-K18 is equipped with a membrane keypad with 24 keys, 12 of which have LED illumination (yellow). The right key block is permanently labeled, and the left key block can be labeled using legend strips. Special insert strips 4A0046.00-000 are available for this purpose which can be printed with a laser printer.
Specifications:
The table below describes the parameters of the 4B1270.00-K18 B&R PANELWARE Membrane Keypad Keyboard.
| Part Number : | 4B1270.00-K18 |
| Product Line: | PANELWARE |
| Warranty: | 365 Days Warranty |
| Input Power: | 24 VDC |
| Display Type: | TFT color |
| Mounting position: | Vertical |
| Input Type: | Keypad |
| Serial interface Type: | RS232 |
Related B&R PANELWARE Series Part No. :
| B&R PANELWARE | Description | Inventory status |
| 4D1165.00-K05 | B&R PANELWARE Operator Keyboard Repair | In Stock |
| 4D1165.00-K08 | PANELWARE B and R Keyboard Membrane Replacement | Available Now |
| 4B1270.00-K09 | B&R PANELWARE Switch Membrane Repair | In Stock |
| 4B1270.00-K15 | PANELWARE B and R HMI Terminal Keypad | Available Now |
| 4B1270.00-K18 | B&R PANELWARE Keyboard Membrane Repair | In Stock |
| 4B1384.00-K07 | B&R PANELWARE Membrane Keypad Keyboard | In Stock |
| 4B1384.00-K08 | B&R PANELWARE Switch Membrane Repair | In Stock |
| 4B1384.00-K14 | B and R PANELWARE Membrane Keypad Replacement | Available Now |
| 4B1384.00-K16 | B&R PANELWARE HMI Switch Membrane Repair | Available Now |
| B and R PANELWARE | Description | Inventory status |
B&R PANELWARE Manuals PDF Download:
FAQ:
Question:How to remove B and R PANELWARE COMPACT 4B1270.00-K18 MMI?
Answer:
• Remove spring clips
• Remove panel
• Remove and reapply sealant before a new installation
• The mounting pins do not have to be removed
Question:How can the PANELWARE 4B1270.00-K18 service life of backlights be extended?
Answer:
• Set the display brightness to the lowest value comfortable for the eyes.
• Use dark images.
• Reducing the brightness by 50% can increase the half-brightness time by approximately 50%.
Common misspellings:
41270.00-K18
4B1720.00-K18
4B127o.00-K18
4B1270.00--K18
