XBTG2110 XBTG2220 Touch Screen Glass Protective Film

XBTG2110 XBTG2220 Touch Screen Glass Protective Film

Detail Information

Schneider Magelis XBTG2110 XBTG2220 Touch Screen Panel Protective Film repair replacement

Order each part separately is available

Schneider Magelis XBTG2110 XBTG2220 Touch Screen Panel Front Overlay

The Magelis XBTG2110 and XBTG2220 are Magelis XBT-G Graphic terminals that can be repair replaced by the same touchscreen and protective film. This touch panel measures 5.7 inches and it is a resistive type that can handle single-touch inputs only. And the screen display type is Monochrome LCD with display dimension of 115.2 x 86.4 millimeters (4.54 x 3.40 inches), screen backlight CCFL (25,000 hrs at25°C and24hr.operation), 4 levels of adjustment available via touch panel.


The XBTG2110 and XBTG2220 unit are grouped together in tables according toSTN screen technology. At normal operating temperatures and conditions, with the XBT-G operating from its lithium battery, the degree of error is 65 seconds per month. Variations in operating conditions and battery life can cause this error to vary from -380 to +90 seconds per month. For systems where this degree of error will be a problem, the user should be sure to monitor this error and make adjustments when required.




Specifications:

The table below describes the parameters of the XBTG2110 XBTG2220 touch screen protective film.

Part Number : XBTG2110 XBTG2220
Product Line: Magelis XBTG Series
Touchscreen Size: 5.7 in.
Warranty: 1-Year Warranty
Touch Technology: Resistive Film (analog)
Resolution: DC 5V 1mA
Operating Temp.: 1024 X 1024
Storage Temp.: -20℃~+70℃
lineation test: ≥1.000.000 times
Input Type: ≥100.000 times

PDF Download:

  • Magelis XBTG2110 User Manual PDF
  • Magelis XBTG2220 User Manual PDF

  • Magelis XBT-G Series Part No.

    Magelis XBTG/GT Description Inventory status
    XBTG2110 Graphic terminals with 5.7'' touchscreen In Stock
    XBTGT2110 Touch Screen Replacement-5.7'' In Stock
    XBTG2120 Graphic terminals with 5.7'' touch panel Call
    XBTGT2120 Touch Membrane Screen-5.7'' In Stock
    XBTG2130 Graphic terminals with 5.7'' touch screen Available Now
    XBTGT2130 Touch Panel Glass -5.7-inch HMI Parts In Stock
    XBTG2220 Graphic terminals with 5.7'' touch-sensitive screens Calss
    XBTGT2220 Touch Screen Panel-5.7'' HMI Part In Stock
    XBTG2330 Graphic terminals with 5.7'' touch-sensitive panel In Stock
    XBTGT2330 advanced touchscreen panel- 5.7" TFT LCD - 24 V DC Available Now
    XBTG4320 Graphic terminals with 7.5'' touch-sensitive screens In Stock
    XBTGT4230 advanced touchscreen panel - 320 x240 QVGA - 7.5" Call
    XBTG4330 Graphic terminals with 7.5'' touch-sensitive panels In Stock
    XBTGT4330 Touch Screen Panel-7.5'' display In Stock
    XBTG5230 Graphic terminals with 10.4'' touch-sensitive screens In Stock
    XBTGT5230 Touchscreen Panel Glass-10.4'' Lcd Display Available Now
    XBTG5330 Graphic terminals with 10.4'' touch screens In Stock
    XBTGT5330 Touch Panel Repair-10.4'' for Replacement In Stock
    XBTG6330 Graphic terminals with 12.1'' touch-sensitive screens Call
    XBTGT6330 advanced touchscreen panel - 800 x 600 pixels - 12.1" In Stock
    Schneider XBT G/GT Description Inventory status

    Common misspellings:

    BTG2110

    XTG2110

    XBG2110

    XBTG220

    XBTG220

    XBTG222


    More Details about Schneider Graphic terminals Model Table
