XBTOT5220 XBTOT5320 Touch Screen Panel Protective Film

XBTOT5220 XBTOT5320 Touch Screen Panel Protective Film

Detail Information

Magelis XBTOT5220 XBTOT5320 Touch Screen Panel Protective Film repair replacement

Order each part separately is available

Schneider Electric XBTOT5220 XBTOT5320 Touch Screen Panel protective film

The Magelis XBTOT5220 and XBTOT5320 are basis HMI panel of Schneider XBT OT series, which allows users to graphically view the machine status and to monitor and manage machine functions. Users can input and set the machine’s parameters through the 45K color trans-missive, thin-film transistor color active matrix, 10.4-inch LCD screen with a display dimension of 10.65in x 8.37in and a resolution of W640 X H480 pixels.


The Schneider XBTOT5220 and XBTOT5320 lithium battery’s lifetime is 10 years when the battery’s ambient temperature is 40°C [104°F] or less. 4.1 years when the battery’s ambient temperature is 50°C[122°F] or less. 1.5 years when the battery’s ambient temperature is 60°C[140°F] or less.


The XBTOT5220 interface Specifications connecting an external device to the OT using the SG terminal, be sure to check that no short-circuit loop is created when you setup the system. The same type of connector is used for the different signal types on COM1 and COM2 of the OT. Be careful not to mistake one for the other. Connecting them incorrectly disables communication.




Specifications:

The table below describes the parameters of the XBTOT5220 XBTOT5320 touch screen protective film.

Part Number : XBTOT5220 XBTOT5320
Product Line: Magelis XBTOT Series
Touchscreen Size: 10.4 in.
Warranty: 1-Year Warranty
Touch Technology: Resistive Film (analog)
Resolution: DC 5V 1mA
Operating Temp.: 1024 X 1024
Storage Temp.: -20℃~+70℃
lineation test: ≥1.000.000 times
Input Type: ≥100.000 times

PDF Download:

  • Magelis XBTOT5220 User Manual PDF
  • Magelis XBTOT5320 User Manual PDF

  • Magelis XBTOT Series Part No.

    Magelis XBT OT Description Inventory status
    XBTOT2110 basis touch panel -5.7-inch In Stock
    XBTOT2210 basis touch panel -5.7-inch In Stock
    XBTOT4310 basis touchscreen -7.5-inch Available Now
    XBTOT4320 basis touch screen -7.5-inch Available Now
    XBTOT5220 basis touchscreen -10.4-inch In Stock
    XBTOT5320 basis touchscreen -10.4-inch Available Now
    Schneider XBT OT Description Inventory status
