Touch screen for GP-104F-5H-NB06B/GP-104F-5H-NB06B Touch screen

Touch screen for GP-104F-5H-NB06B/GP-104F-5H-NB06B Touch screen

Touch screen for GP-104F-5H-NB06B/GP-104F-5H-NB06B Touch screen
Touch screen for GP-104F-5H-NB06B/GP-104F-5H-NB06B Touch screenTouch screen for GP-104F-5H-NB06B/GP-104F-5H-NB06B Touch screenTouch screen for GP-104F-5H-NB06B/GP-104F-5H-NB06B Touch screen
CategoriesGtouch Screen
BrandVICPAS
ModelGP-104F-5H-NB06B
Touch screen panel typeResistance touch screen
Size10.4 inch
BrandGtouch Touch Screen
Shipping2-4 workdays
Supply PartsGtouch GP-104F-5H-NB06B Touchscreen Panel
Warranty365 Days
Part NumberGP-104F-5H-NB06B
FOB portGuangzhou, Shenzhen, Hongkong
Terms of PaymentWestern Union, T/T, PayPal, Credit Card
Update TimeDec 23,2024
Detail Information

Gtouch GP-104F-5H-NB06B HMI Panel Glass HMI Replacement


Gtouch GP-104F-5H-NB06B Touch Screen Panel repair replacement

GP-104F-5H-NB06B touch panel is composed of a layer of a conductive film (ITO Film) and a layer of conductive glass (ITO Glass). The GP-104F-5H-NB06B Touch Digitizer Spacer Dots is also used for insulation between the film and glass. The five-wire resistive GP-104F-5H-NB06B HMI Panel Glass is designed according to this structure, since its main X-axis or Y-axis line is not on the outermost film but on the glass, so the durability and reliability are different to the 4-wire resistive product. The difference between 5-wire and 4-wire is that for 5-wire both the X-axis and Y-axis are made on the glass surface, and the upper ITO Film is only used for grounding. The X-axis and Y-axis are respectively routed from the four corners of the action area, and the positive voltage forms a loop with the grounding wire. The voltage value also forms a uniform electric field, and the coordinate position is detected by calculation.




Specifications:

The table below describes the parameters of the Gtouch GP-104F-5H-NB06B Touch Membrane HMI Part.

Brand: Gtouch
Connection Tail: FFC or FPC
Linearity: <1.5%
Operation Temperature: -10℃~ 70℃
Product Line: Gtouch Touch Panel
Storage Temperature: -40℃~+80℃
Touch Size: 10.4 inches
Top Layer: Polyester film
Transparency: 80%
Warranty: 1-Year Warranty


Related Gtouch Touch Screen HMI Part No. :

Gtouch Touch Membrane Description Inventory status
GP-101F-5M-NB02B Gtouch Touch Screen Glass HMI Repair Available Now
GP-101F-5M-NB03B Gtouch Touch Screen Panel Replacement In Stock
GP-101F-5M-NB04B Gtouch Touch Panel Replacement Available Now
GP-101F-5M-NB05B Gtouch Touch Membrane Replacement In Stock
GP-102F-5H-NB01A Gtouch Touch Glass Replacement In Stock
GP-102F-5H-NB01B Gtouch HMI Panel Glass Replacement Available Now
GP-102F-5H-NB02B Gtouch Touch Digitizer Glass Repair Available Now
GP-102F-5H-NB11B Gtouch Touch Panel Repair Replacement In Stock
GP-104F-5H-3G Gtouch HMI Touch Glass Replacement Part In Stock
GP-104F-5H-B06 Gtouch MMI Touch Screen Replacement Repair In Stock
GP-104F-5H-NB06B Gtouch Touch Screen Panel Replacement Available Now
GP-104F-5H-NB11A Gtouch Touch Screen Glass Replacement In Stock
GP-104F-5H-NB11B Gtouch Touch Screen Panel Replacement Available Now
GP-104F-5M-NA03B Gtouch Touchscreen Repair Part In Stock
GP-104F-5M-NB06B Gtouch Touch Digitizer Replacement Repair In Stock
Gtouch Touch Digitizer Description Inventory status
