Disassembly Instructions
Follow the basic steps that should typically be followed to remove components and materials.
1. Disassembly 15 pcs screw to remove the rear cover. Pay attention not to drop Advantech HMI Panel PC Series PPC-3100S PPC-3100S-RB PPC-3100S-RBE Front Overlay Touch Screen Glass to the ground.
2. Disassembly 3 pcs screw to remove the control Board.
3. Disassembly 4 pcs screw to remove the AD board.
4. Disassembly 4 pcs screw to remove the power board and ensure Advantech screen PPC-3100S-RB PPC-3100S-RBE Touch Panel Front Overlay is disconnected.
5. Disassembly 3 pcs screw to remove the lO bracket.
6. Take HMI Advantech PPC-3100S-RB PPC-3100S-RBE Touch Digitizer Glass Protective Film off before disassembly 9 pcs screw 4 pcs post to remove the middle bracket.
7. Disassembly screw 4 pcs to separate the LCD bracket left and right with LCD module.
8. Disassembly 1 pcs screw to remove the LED board.
9. Remove the waterproof from front bezel of Advantech touch screen PPC-3100S-RB PPC-3100S-RBE Protective Film HMI Panel Screen.
Specifications:
The table below describes the parameters of the Advantech Panel PC Series PPC-3100S PPC-3100S-RB PPC-3100S-RBE Touch Membrane Front Overlay.
| Display Type: | SVGA/XGA LED LCD |
| Storage Temperature : | -40 ~ 60 °C (-40 ~ 140 °F) |
| Product Line: | PPC-3100S Series |
| LCD Resolution: | 800 x 600 Pixels |
| Display Size: | 10.4'' |
| Warranty: | 1-Year Warranty |
| Relative Humidity: | 95%RH |
| Brand: | Advantech |
| Operating Temperature: | 0 ~ 50 °C (32 ~ 122 °F) |
| Front Panel Protection: | IP66 |
Related Advantech HMI No. :
| Advantech HMI | Description | Inventory status |
| PPC-3120S-N20BE | Advantech Panel PC Series LCD Screen Touch Screen Film Front Overlay Replacement | In Stock |
| PPC-3120S-N22AE | Advantech Panel PC Series Protective Film Touch Screen LCD Panel Repair | Available Now |
| PPC-3120S-N22BE | Advantech Panel PC Series Touch Panel LCD Display Front Overlay Replacement | In Stock |
| PPC-3120S-N24AE | Advantech Panel PC Series LCD Display Screen Protective Film Touch Membrane Repair | Available Now |
| PPC-3120S-N24BE | Advantech Panel PC Series LCD Display Panel Touchscreen Front Overlay Replacement | In Stock |
| PPC-3120S-N28AE | Advantech Panel PC Series Front Overlay LCD Display Screen Touch Screen Film Repair | Available Now |
| PPC-3120S-N28BE | Advantech Panel PC Series Touch Screen Glass Protective Film LCD Screen Replacement | In Stock |
| PPC-3120S-PAE | Advantech Panel PC Series LCD Display HMI Touch Glass Front Overlay Repair | Available Now |
| PPC-3120S-PBE | Advantech Panel PC Series Protective Film LCD Panel Touchscreen Replacement | In Stock |
| PPC-3120S-RAE | Advantech Panel PC Series Touch Screen Display Front Overlay LCD Display Repair | Available Now |
| PPC-3120S-RB | Advantech Panel PC Series LCD Display Screen Protective Film Touch Panel Replacement | In Stock |
| PPC-3120S-RBE | Advantech Panel PC Series Front Overlay LCD Panel Touch Digitizer Repair | Available Now |
| PPC3150S1701E-T | Advantech Panel PC Series Touch Panel Protective Film Replacement | In Stock |
| PPC3150S1702E-T | Advantech Panel PC Series Protective Film Touchscreen Repair | Available Now |
| PPC3150S1703E-T | Advantech Panel PC Series Touch Panel Front Overlay Replacement | In Stock |
| PPC3150S1704E-T | Advantech Panel PC Series Protective Film Touch Membrane Repair | Available Now |
| PPC3150S1801E-T | Advantech Panel PC Series Touch Screen Front Overlay Replacement | In Stock |
| PPC3150S1802E-T | Advantech Panel PC Series Protective Film Touch Screen Repair | Available Now |
| Advantech HMI | Description | Inventory status |
Advantech HMI Manuals PDF Download:
FAQ:
Question: Which way can I finish the mounting without causing damage to Advantech PPC-3100S-RB PPC-3100S-RBE Touch Digitizer Glass Front Overlay?
Answer: Wall mounting, panel mounting, arm mounting and stand mounting will not do harm to PPC-3100S-RB PPC-3100S-RBE Touch Panel Protective Film.
Question: What is the backlight lifetime of Advantech PPC-3100S Series LCD?
Answer: The backlight lifetime of Advantech PPC-3100S Series LCD is 70,000 hr (min.).
Question: What is the price of Advantech PPC-3100S-RB PPC-3100S-RBE Front Overlay Touch Screen Glass?
Answer: Submit a fast quote, send VICPAS an email for best price.
