Beijer HMI iX T5F Touchscreen Protective Film Replacement
The iX T5F Protective Film Touch Digitizer Glass HMI is a 5-inch industrial operator panel with high-resolution touch screen and modern design. The iX T5F Touch screen panel glass Front Overlay model combines IP65 plastic housing with the full version of the iX HMI software, making it a cost-effective yet advanced HMI. The iX T5F HMI panel offers Ethernet, serial and USB ports as standard.
▪ 5”, 800 × 480 pixel (16:9), TFT-LCD touch screen
▪ Application storage 200 MB
▪ 1 × Ethernet, 4 × serial, 1 × USB as standard
▪ Operating temperature -10 to +50 °C
▪ UL / cUL, CE, FCC and KCC certifications
VICPAS supply Beijer iX T5F Touch Panel and Front Overlay with 365 days warranty and support Urgent Worldwide Shipping.
Specifications:
The table below describes the parameters of the Beijer iX T5F HMI Parts.
| Brand: | Beijer |
| Part number: | iX T5F |
| Size: | 5 INCH |
| Warranty: | 365 Days Warranty |
| Power voltage: | +24 VDC |
| Size diagonal: | 800x480 pixel |
| Display type: | TFT-LCD |
| Touch type: | Resistive |
| Backlight: | LED |
| Brightness: | 300 cd/m2 |
Beijer iX TxX Touch Panel HMI Manuals PDF Download:
FAQ:
Question: How to ground the iX TxX Series Operator Panel?
Answer:1. Connect a 2.5mm2 wire between the operator panel’s quick-connect plinth and the panel’s chassis, see 2 in drawing above.
2. Connect a 6mm2 or 4mm2 wire or grounding braid between the operator panel’s chassis and the closest grounding point on the door, see 3 in drawing above.
3. Connect a strong but short grounding braid between the door and the devicecabinet, see 4 in drawing above.
4. Twist the cables onto the 24VDCfeed, see 5 in drawing above. Minimumcross-section of the cable is 2.5mm2.2 turns around the ferrite core provide 4 times the suppression of 1 turn.3 turns around the ferrite core provide 9 times the suppression of 1 turn.
Question: Why the Beijer iX T5F HMI have the chemical resistance?
Answer: iX T5F covers the overlay surrounding the screen.
Question: What is Beijer iX T5F Touchscreen and Overlay HMI parts price?
Answer: Submit a fast quote, send VICPAS an email for best price.
Common misspellings:
iX TFiX 5TF
iX 75F
iX T55F
