CP552 1SBP260177R1001 Glass Screen Film Repair
| Categories | Control Panel 500 |
|---|---|
| Brand | VICPAS |
| Model | CP552 1SBP260177R1001 |
| Warranty | 365 Days |
| Product Line | Control Panel 500 Series |
| Types | Resistive Touch Panel and Protective Film |
| Shipping | 2-3 workdays |
| Brand | Vicpas |
| FOB port | Guangzhou, Shenzhen, Hongkong |
| Terms of Payment | Western Union, MoneyGram, T/T, Paypal, PayPal, Credit Card |
| Update Time | Dec 23,2024 |
Control Panel 500 Series CP552 1SBP260177R1001 Resistive Touch Screen Front Overlay Repair
Order each part separately is available
System Monitor. Only applicable for CP551, CP552, CP554, CP513 and CP555. The system monitor is a block where the operator can view or change the values for control signals in run mode. The values are presented as decimal, hexadecimal and ASCII values. The system monitor is always available in the operator terminals. To use the system monitor during run mode you create a block jump from another block to the system monitor block. The editing box is needed to add on control signals.
Contrast Setting. Applicable for CP511, CP512, CP552, and CP513: The contrast settings are made in the programming mode under Setup/Contrast setting or in run mode through a jump to system block 997. By pressing on the function key + the display becomes brighter, and by pressing on - it becomes darker. Return to the previous level by pressing EXIT.
VICPAS supply Control Panel 500 Series CP552 1SBP260177R1001 Touch Screen Panel and Protective Film with 365 Days warranty and support Urgent Worldwide Shipping.
Specifications:
The table below describes the parameters of the CP552 1SBP260177R1001 Control Panel 500 Series.
| Part Number: | CP552 1SBP260177R1001 |
| Display Size: | 320 × 240 Pixels |
| Ambient Temperature: | 0 … +50 °C |
| Display Area: | 115.2 × 86.4 |
| Communication Interface: | RS232 and RS422 or RS485 |
| Part Type: | New |
| Order Multiple: | 1 piece |
| Operating Temperature: | 0 … +50 °C |
| Storage Temperature: | -20 … +70 °C |
| Warranty: | 365 Days |
Related Control Panel 500 Series Terminals Part No. :
| Control Panel 500 Series | Description | Inventory status |
| CP501 1SBP260170R1001 | CP501 1SBP260170R1001 Operator Panel Keypad Repair | In Stock |
| CP502 1SBP260171R1001 | CP502 1SBP260171R1001 Membrane Keypad Repair | Available Now |
| CP503 1SBP260172R1001 | CP503 1SBP260172R1001 Membrane Switch Repair | In Stock |
| CP511 1SBP260173R1001 | CP511 1SBP260173R1001 5.2'' Operator Keyboard Repair | Available Now |
| CP512 1SBP260174R1001 | CP512 1SBP260174R1001 5.3'' Membrane Keyboard Repair | In Stock |
| CP513 1SBP260175R1001 | CP513 1SBP260175R1001 Membrane Keypad Switch Repair | In Stock |
| CP551 1SBP260176R1001 | CP551 1SBP260176R1001 3.8'' Touch Screen Overlay Repair | In Stock |
| CP554 1SBP260178R1001 | CP554 1SBP260178R1001 Protective Film Touchscreen Repair | In Stock |
| CP555 1SBP260179R1001 | CP555 1SBP260179R1001 Overlay Panel Glass Repair | Available Now |
| Control Panel 500 HMI | Description | Inventory status |
Control Panel 500 HMI Manuals PDF Download:
FAQ:
Question: What is the price of CP552 1SBP260177R1001 Touch Digitizer Glass and Front Overlay?
Answer: Submit a fast quote, send VICPAS an email for best price.
Question: How to set in the PC?
Answer:
1. Select the function New Connection Wizard according to the following search path: Start\All Programs\Accessories\Communication\New Connection Wizard.
2. Select Set up an advanced connection and click Next.
3. Select Connect directly to an other computer in the Advanced Connection Options dialog and click Next.
4. Select Guest and click Next.
5. Enter a name for the connection, for example “PPP”, and click Next.
6. Select the device (the modem) Comminications cable between two computers (COMx) in the drop-down menu and click Next.
7. Complete the New Connection Wizard by clicking Finish. The Connect dialog is now shown.
8. Click on Properties and make the settings.
9. Click on the Networking tab and make sure that only the Internet Protocol (TCP/IP) is checked.
10.Click on the Advanced tab and make the settings.
