Panasonic AWHS1R043 AWHS1R070 AWHS1R101 Film Touch Panel

Panasonic AWHS1R043 AWHS1R070 AWHS1R101 Film Touch Panel

Panasonic AWHS1R043 AWHS1R070 AWHS1R101 Film Touch Panel
Panasonic AWHS1R043 AWHS1R070 AWHS1R101 Film Touch PanelPanasonic AWHS1R043 AWHS1R070 AWHS1R101 Film Touch PanelPanasonic AWHS1R043 AWHS1R070 AWHS1R101 Film Touch PanelPanasonic AWHS1R043 AWHS1R070 AWHS1R101 Film Touch PanelPanasonic AWHS1R043 AWHS1R070 AWHS1R101 Film Touch Panel
CategoriesOther Panasonic Terminal Repair Kit
BrandVICPAS
ModelAWHS1R043 AWHS1R070 AWHS1R101
BrandPanasonic
Size4.3, 7, 10.1 inch
Warranty365 Days
Part NumberAWHS1R043 AWHS1R070 AWHS1R101
SupplyPanasonic Touch Screen and Overlay
Shipping2-4 workdays
Terms of PaymentWestern Union, T/T, PayPal, Credit Card
Update TimeDec 25,2024
Detail Information

Panasonic WH AWHS1R043 AWHS1R070 AWHS1R101 Touch Screen Protective Film Replacement

Order each part separately is available

Panasonic WH WHS1 AWHS1R043 AWHS1R070 AWHS1R101 Touch Screen Front Overlay Repair Replacement

VICPAS supply Panasonic WHS1 AWHS1R043 AWHS1R070 AWHS1R101 Protective Film and Touch Panel with 365 days warranty and support Urgent Worldwide Shipping. Before You Start Panasonic WH AWHS1R043 AWHS1R070 AWHS1R101
■ Usage conditions
 Ambient temperatures: 0 to 50 °C
 Ambient humidity should be 5 to 85% RH (at +25 °C and non-condensing.)
 Usable altitude: 2000 m above sea level or lower
 For use in pollution degree 2 environment
 Do not use it in the following environments.
- Direct sunlight, wind and rain. (This product is not designed for outdoor use.)
- Inflammable or corrosive gas.
- Excessive airborne dust, metal particles or saline matter.
- Benzine, paint thinner, alcohol or other organic solvents or strong alkaline solutions such as ammonia or caustic soda.
- Direct vibration, shock or places always exposed to drop of water.
- This unit is warranted by IP66, IP20 for panel mounting, however, this applies to initial values and evaluated by us.
- Influence from power transmission lines, high voltage equipment, power cables, power equipment, radio transmitters, or any other equipment that would generate high switching surges. (100 mm or more)
 The vents in the AWHS1R043 AWHS1R070 AWHS1R101panel casing must not be obstructed.


■ Touch switches
 Always operate the AWHS1R043 AWHS1R070 AWHS1R101 touch switches with fingers. As the touch switches may be damaged due to the excessive load or shock (caused when being operated with any tools), the touch switches should be operated within the specified control force. Also, if the AWHS1R043 AWHS1R070 AWHS1R101 touch switches are pressed like kneading, the electrode may be worn out exceptionally, and cause the malfunction. Operate with a single touch of a switch.
 The AWHS1R043 AWHS1R070 AWHS1R101 touch position may shift due to aging variation. If the touch position has shifted, please adjust it.




Specifications:

The table below describes the parameters of the Panasonic WH WHS1 AWHS1R043 AWHS1R070 AWHS1R101 Protective Film Touch Panel HMI Parts.

Ambient Temperature: 0 to +50 °C
Ambient Humidity: 5 to 85% RH
Backlight: 1-color LED
Brand: Panasonic
Display Type: TFT color LCD
Product Line: Panasonic WHS1
Storage Temperature: -20 to +70℃
Storage Humidity: 5 to 85%RH
Touch Size: 4.3",7", 10.1"
Warranty: 12 Months Warranty


Panasonic WH Series HMI Manuals PDF Download:

  • Panasonic WHA1 Series User's Manual
  • Panasonic WHS1 Series User's Manual

  • FAQ:

    Question: What is size of Panasonic WHS1 AWHS1R043 AWHS1R070 AWHS1R101 Touch Screen and Protective Film HMI parts price?

    Answer: The Panasonic WH AWHS1R043 AWHS1R070 AWHS1R101 Front Overlay and Touchscreen Panel Glass are 4.3, 7 and 10.1 inch.


    Question: What is the installation method of Panasonic WH AWHS1R043 AWHS1R070 AWHS1R101?

    Answer: Place the fixing brackets contained in the fixing kit.
    Tightening torque: 0.75N・m or screw each fixing screw until the bezel corner gets in contact with the panel.
    What is the installation method of Panasonic WH AWHS1R043 AWHS1R070 AWHS1R101?

    Common misspellings:

    AWHS1R043 AWH1R070 AWHS1R101
    AHS1R043 AWHS1R070 AWHS1R101
    AWHS1R043 AWHS1R700 AWHS1R101
    AWHS1R043 AWHS1R070 AWHS1RI01
    AWHS1R0043 AWHS1R070 AWHS1R101
