ESA IT Touch Screen Terminal HCJ-015.8200.930.1 Replacement

ESA IT Touch Screen Terminal HCJ-015.8200.930.1 Replacement

ESA IT Touch Screen Terminal HCJ-015.8200.930.1 Replacement
CategoriesIT Touch
BrandVICPAS
ModelHCJ-015.8200.930.1
BrandESA
Size5.7 inch
Warranty365 Days
Product LineTouch screen terminals
SupplyHCJ-015.8200.930.1 Touch Screen
Terms of PaymentWestern Union, T/T, PayPal, Credit Card
Download
Update TimeNov 21,2024
Detail Information

ESA Touch Screen HCJ-015.8200.930.1 Touch Screen Replacement


ESA Touchscreen Terminal HCJ-015.8200.930.1 Touch Screen Protective Film Repair Replacement

ESA HCJ-015.8200.930.1 5,7“ STN 320x240 16 tones of bule Touch Screen Front Overlay Terminal Repair Kit, which in clude touchscreen and protective flim


HCJ-015.8200.930.1 operator terminals ensure maximum availability of drivers and a full coverage of the PLC market and of otherdevices, such as drives, inverters and temperature controllers, including:
• Profibus-DP at 12 Mbit/s (addressing up to 127 terminals)

• Interbus-S at 500 Kbit/s (addressing up to 127 terminals)

• CAN (through built-in port or external adapter)

• Modbus in master and slave mode

• TCP/IP protocol support


VICPAS supply ESA Touchscreen Terminal HCJ-015.8200.930.1 Touch Panel with 365 days warranty and support Urgent Worldwide Shipping.





Specifications:

The table below describes the parameters of the ESA HCJ-015.8200.930.1 HMI Parts.

Brand: ESA
Resolution: 320 x 240 pixel
Size: 5.7 INCH
Warranty: 6-Months Warranty
Product Line: Touch Terminal
Display Type: Graphic LCD STN
Backlight: CCFL
Touch screen: Analog
Input voltage: 18 - 32 V DC
Part Number: HCJ-015.8200.930.1



ESA Operator Panel HMI Manuals PDF Download:

  • ESA HMI IT Series Manuals
  • ESA IT Touchscreen Terminal datasheet pdf


  • FAQ:

    Question: How to collect and process the HCJ-015.8200.930.1 data?

    Answer:The operator panels in the IT range can be connected to a production plantand the production data can be exported directly to a remote PC throughthe integrated Ethernet port. Just indicate the names of the variables to bemonitored and, when necessary, their values are automatically read by thePLC and processed directly in an Excel file. In addition, the file can be savedon removable media devices automatically or on a shared folder on aremote PC.


    Question: What is the HCJ-015.8200.930.1 Termination of CAN line?

    Answer:The VT in question integratesthe termination resistances of the serial line (typically 120 ohms)which can be inserted by means of a jumper (preset on 1-2, line not terminated).To activate the termination:
    • Make sure the device is not connected to the power supply.
    • Remove the cover.
    • Identify the jumper unit J2.
    • Position the jumper between pins 2 and 3 (line terminated).
    • Replace the back cover.
    • Reconnect the power supply.


    Question: What is ESA HCJ-015.8200.930.1 Touch Screen and Protective Film HMI parts price?

    Answer: Submit a fast quote, send VICPAS an email for best price.

    Common misspellings:

    HCJ-015.820.930.1
    HCJ-015.8200.903.1
    HCJ-0l5.8200.930.1
    HCJ-015.8200.9330.1
