DMC AST-190A140A Touch Screen Panel 100% Original
New Original DMC AST-190A140A 19'' 4-Wire Resistive Touch Panel Screen Glass Repair Replacement
The DMC AST-190A140A screen size is 19 inches, 4 wire resistive touch screen panel glass. The touch screen External Dimension is 400.6 x 308.3mm, Viewing Area Dimension 136.98 x 103.86mm, Active Area Dimension 302 x 377.3mm, and Glass Thickness 1.1/ 1.4mm. Per dmc touch screen had been full text before ship to customers.
The AST-190A140A touch panel Electrical Characteristics use DC6V Maximum Voltage, and the connetion Top Electrode within 100mA, Between the Top and Bottom is 0.5mA. It have long Operating Life with 10,000,000 hits Input (finger).
VICPAS supply DMC AST-190A140A touchscreen panel for repair replacement. Each DMC AST-190A140A touch screen will be tested before shipment, and will be tested in all aspects from appearance and function. Only when all aspects of performance are normal will the shipment be arranged
Specifications:
The table below describes the parameters of the DMC AST-190A140A Touchscreen Panel Glass.
| Part Number : | AST-190A140A |
| Product Line: | Resistive Touchscreen |
| Screen diagonal | 19 in |
| Warranty: | 365 Days Warranty |
| Input Power | 24 VDC |
| Display Type: | Resistive Touchscreen |
| Mounting position: | Vertical |
| Input Type: | Touchscreen |
| Serial interface Type: | RS232 |
| Storage | -20 to 70°C |
Click the video to learn more about DMC AST-190A140A touch screen glass details
DMC AST-190A140A Datasheet / USER Manuals PDF Download:
FAQ:
Question:What technology is used to produce DMC AST-190A140A touch panel?
Answer: DMC AST-190A140A touch screen is produced with 4-wire resistive screen technology, Resistive touchscreens consist of two layers of polyethylene terephthalate (PET) with ITO coated on each layer. The two layers of PET are separated by an air gap and spacer dots.
The bottom PET layer is placed on top of an insulating substrate usually made of glass. A protective layer of hard coating is placed on top of the other PET layer.
When a finger presses onto the touchscreen, the action causes the top and bottom ITO layers to physically come in contact, which signifies a finger touchdown. Resistive touchscreens come in 4-, 5-, 6-, and 8-wire variants, which offer different degrees of durability and noise suppression.
Question: What is the DMC AST-190A140A touch screen panel price?
Answer: Submit a fast quote, send VICPAS an email for best price.
Common misspellings:
ST-190A140A
AT-190A140A
AS-190A140A
AST190A140A
AST-90A140A
AST-10A140A
AST-19A140A
AST-190140A
AST-190A40A
AST-190A10A
AST-190A14A
AST-190A140
