ESA Terminals HMI VT515W 000CN Touch Panel Replacement
![ESA Terminals HMI VT515W 000CN Touch Panel Replacement](https://icdn.tradew.com/file/201606/1569362/jpg/7621412.jpg?x-oss-process=image/resize,m_pad,l_450/quality,Q_90)
![ESA Terminals HMI VT515W 000CN Touch Panel Replacement](https://icdn.tradew.com/file/201606/1569362/jpg/7621412.jpg?x-oss-process=image/resize,m_pad,l_40/quality,Q_90)
![ESA Terminals HMI VT515W 000CN Touch Panel Replacement](https://icdn.tradew.com/file/201606/1569362/jpg/7621404.jpg?x-oss-process=image/resize,m_pad,l_40/quality,Q_90)
![ESA Terminals HMI VT515W 000CN Touch Panel Replacement](https://icdn.tradew.com/file/201606/1569362/jpg/7621405.jpg?x-oss-process=image/resize,m_pad,l_40/quality,Q_90)
![ESA Terminals HMI VT515W 000CN Touch Panel Replacement](https://icdn.tradew.com/file/201606/1569362/jpg/7621410.jpg?x-oss-process=image/resize,m_pad,l_40/quality,Q_90)
![ESA Terminals HMI VT515W 000CN Touch Panel Replacement](https://icdn.tradew.com/file/201606/1569362/jpg/7621409.jpg?x-oss-process=image/resize,m_pad,l_40/quality,Q_90)
ESA Touch Screen Protective Film VT515W VT515W000CN Touch Panel Replacement
Order each part separately is available
![ESA Touchscreen Terminal VT515W VT515W000CN Touch Screen Protective Film Repair Replacement ESA Touchscreen Protective Film VT515W VT515W000CN Touch Screen Repair Replacement](https://icdn.tradew.com/file/201606/1569362/jpg/7621416.jpg)
VT515W000CN with 5,7” graphic STN LCD display, 4blue levels, 16 rows by 40 characters(320 x 240), Touch-Screen, 640 KBproject, software clock, 16 KB recipes,10 mt cable
ESA VT515W Main characteristics (modeldependant): High value solution formany applications Alarms, passwords, recipes Use of Windows® fonts Importation of graphicimages in any format Moving graphic objects Serial printing Integrated Profibus-DP andCAN Integrated Ethernet 10/100
VICPAS supply ESA Touchscreen Terminal VT515W Touch Panel Front Overlay with 365 days warranty and support Urgent Worldwide Shipping.
Specifications:
The table below describes the parameters of the ESA VT515W000CN HMI Parts.
Brand: | ESA |
Resolution: | 320 x 240 |
ASP serial port1: | RS232 (8 pin) |
Warranty: | 6-Months Warranty |
Product Line: | Touch Terminal |
Display Type: | Graphic LCD TFT |
Touch Screen Matrix: | 20x16 |
Display area size: | 115,17 x 86,37 (mm) |
Size: | 5.7" |
Part Number: | VT515W000CN |
Related ESA VT515W Part No. :
ESA VT515W | Description | Inventory status |
VT515W 000ET | ESA Terminals HMI VT515W 000ET Touch Screen Replacement | In Stock |
VT515W000DP | ESA Terminals HMI VT515W 000DP Touch Panel Replacement | In Stock |
VT515W000CN | ESA Terminals HMI VT515W 000CN Touch Panel Replacement | In Stock |
VT515W00000 | ESA Terminals HMI VT515W 00000 Touch Screen Replacement | In Stock |
ESA VT TEXT | Description | Inventory status |
ESA VT515W Operator Panel HMI Manuals PDF Download:
FAQ:
Question: How to operate the VT515W Terminal with Front Overlay touchscreen?
Answer:To be able to carry out a change in any editable variable field you musttouch the chosen field on the display and a page appears offering theneeded to modify the field.
Question: What is the VT515W Termination of CAN line?
Answer:The VT in question integratesthe termination resistances of the serial line (typically 120 ohms)which can be inserted by means of a jumper (preset on 1-2, line not terminated).To activate the termination:
• Make sure the device is not connected to the power supply.
• Remove the cover.
• Identify the jumper unit J2.
• Position the jumper between pins 2 and 3 (line terminated).
• Replace the back cover.
• Reconnect the power supply.
Question: What is ESA VT515W Touch Screen and Protective Film HMI parts price?
Answer: Submit a fast quote, send VICPAS an email for best price.
Common misspellings:
V515W000CNVT15W000CN
VT55W000CN
VT51W000CN
VT515000CN
